You missed the memo once again from post #475
To repeat:
"
Too much to dissemble here, but:
1. P-47M/N. First YP-47M - installed R-2800-14W, then changed to turbo'd -57 version. Otherwise P-47D-27 fuselage and wing. Hot rod which went to 56th beginning late December 1944, major issues with engine harness lingering through March 1945 - and precluded full combat ops until April 1945. Combat radius same as P-47D-25 & Subs ~ 550 mi. The P-47N major distinctions were twofold - plug/insert in each wing to extend span to 42 feet from 40 feet w/squared tips. Major wing mods to install additional fuel, wider tread/stronger tires, reinforced spars and stringers. Source P-47 drawing package Aero Libraries
The first delivered September 1944 - First deployment April 1945. Source - Individual Aircraft Record Cards via USAFHRC, Maxwell AFB, Group and Squadron histories contained in Olynyk's Stars and Bars, Maurer's Air Force Unit histories, Freeman, Bodie.
2. The Defined AAF Combat Radius for the P-47N was 1000 mi with 550 gal internal plus 2x220gal external. It could carry more but limited to both tire integrity questions and length of takeoff run- exceeding most runways save operational bomber bases. AAF Published Combat Radius Tables - source Wright Patterson Field 1945
3. The Defined AAF Combat Radius of the P-47M was 600 mi with 370 internal plus 2x150 gal external. Very slightly less than P-47D-25 due to more fuel consumption for C series engine. AAF Published Combat Radius Tables - source Wright Patterson Field 1945. Also published by Dean in "America's One Hundred Thousand"
Contrary to opinion of those without technical acumen, there IS a law of diminishing returns for continuous additions of fuel - both for internal and significantly for external stores. The P-47D had the ABILITYto mount C/L plus two pylon external tanks. The result was a combination of significant drag issues due to the extenal stores as well as Induced Drag for increased weight of combined airframe and external stores. At optimal cruise settings for optimal range, the airspeed for 3 store config was 20+mph at higher angle of attack (than 2 store 150s), and 70mph below clean (except for pylons) airframe. The net result was questionable increase in combat radius but a substantial increase to hazardous take offs due to the gross weight overload. Not to mention extremely high operations cost compared to Merlin equipped P-51.
The first action to improve range via wing strengthening was the P-47D-6 and D-10-RE in delivered in July/Aug timeframe. Several 'special' D-5s were modified with attach points on the wing and plumbing - similar to P-51 type pylons and used with 165 gal Lockheed Ferry tanks in August 1943. Source - P-47 Drawing Package Aero Library, Freeman, Bodie, P-47 Individual Aircraft Records via USAF HRC
The first factory pylon installation was not completed until late October and reached ETO in March/April with P-47D-15-RE. Source - P-47 Drawing Package Aero Library, Freeman, Bodie, P-47 IARC's
In parallel, beginning ~ December 1943, BAD1 Burtonwood began modifying C's and D's to Republic specs for wing srengthening and plumbing in attempt to accelerate wing pylon introduction into combat ops. They began dribbling into VIII FC in Febuary 1944 strengthened for up to 2x150gal tanks. Those were capable of 425 mi Combat Radius. That said, group level strength of Depot mods plus arriving P-47D-15/-16 was insufficient for a full group mission with all mission P-47s capable of Celle/Hanover. The FIRST LR escort with full P-47D-25 (with 370 vs 305 gal internal fuel) capability was a rare excursion to Leipzig on July 7, 1944. Sources - 8th AF Operational Summaries via USAFHRC, Roger Freeman "Mighty Eighth War Manual", 8th AF Victory Credits June 1945 citing location of VCs by pilot and unit and date, as well as Missing Aircrew Records citing date, unit, engine serial no., etc., and location of MIA aircraft and crews.
By that time, Doolitle/Spaatz had already started conversion of the P-38J to P-51B/D and shipment to 9th and 15th AF FG's. The conversion to P-51Bs from P-47D started w/4th & 355th in February, then 352nd in April, and 359/361 in May, 1944. Too many sources to name but Freeman's Mighty Eighth is a start, Miller's ighter Units and Pilots of the Eighth AF, Marshall's "Our Might Always - History of the 355th FG and Marshall/Frd "P-51B Mustang; North merican's Bastard Stepchild that Saved Eighth AF" for a couple.
For the record, what Arnold did was order the development of the sealed combat tanks by Materiel Command in February 1942 at the end of the Fighter Conference. Multiple sources again - but start with Boylon's USAF STUDY 136 Development of Long Range Fighter
